12V 12000BTU Air Conditioner Mini Split A/C For Semi Trucks Bus RV
Caravan VansUSD $496.99
Condition : New
Free Shipping
{{variant_type_name}} :
Notify me when the price drops
We will email you if we find a lower price on this product!
You May Like 12V Rooftop Air Conditioner Electric AC Rooftop unit For RV Motorhome Caravan US BUY NOW Split AC Truck Air Conditioner 12V 11000 BTU For Semi Car Trucks Bus RV Caravan BUY NOW Split AC Truck Air Conditioner 24V 11000 BTU For Semi Car Trucks Bus RV Caravan BUY NOW
Control panel and remote control---Intelligent, convenient, comfortable.Intelligent panel temperature setting and four frequency modulation modes.Convenient infrared remote control. Strong refrigeration---After stopping and extinguishing, it can continue to run for 8-12 hours to save energy and electricity, protect the environment, promote health, and sustain reshaping 4 working mode---Air supply mode，Power saving mode，Economic mode，Strong mode.Highefficency Fan --360 degree full waterproofelectronic Fan.High Quality Condenser --Special surface treatment,corrosion resistance,larger heat disssipation area,better refrigeration effect.Inverter scroll comcompressor--Intelligent inverter scroll compressor,more powerful and cooling faster.Often drivers leave the engine running for hours to use the air conditioner when parked or resting at night, which is bad for the environment, wastes a lot of fuel and wears out the engine faster. The parking air conditioner is powered by truck batteries and does not require an engine, saving energy and fuel while providing a safe and comfortable environment for the driver.Wide range of uses, suitable for trucks, RVs, vans, passenger cars, excavators, agricultural vehicles, boats, engineering vehicles, etc.Scroll compressorr: compared with other compressors, whether in terms of refrigeration efficiency or working efficiency, this compressor The compressor has nearly doubled the efficiency, which is better than the traditional split compressor refrigeration. Powered by an on-board battery, it keeps your cab cool even when the engine is off.
Matters needing attention1、 There is no refrigerant inside the air conditioner, and 500-550g R1234yf/R134a needs to be added 2、Refrigeration oil type: POE68(included)3、Vacuum for 10 minutes before adding refrigerant until the low pressure gauge shows a negative value.4、Parking air conditioning Battery Requirements
12V: At least 100AH single battery and 70A generator are required.
24V: At least 80AH single battery and 60A generator are required.
Install the external machine: remove the casing, mark the drilling position, use an 8mm drill to drill holes, use a riveting tool to fix the rivet nut at the drilling point, install shock pads and sleeves at the holes of the external machine, and fix the external machine to the car .Install the expansion valve: remove the iron sheet at the position of the expansion valve of the evaporator, and fix the expansion valve to the evaporator. The two black screws correspond to the two holes, so there is no need to worry about wrong installation.Then wrap it in black cotton wrap.Install the indoor unit: first install the wooden board to the indoor wall, and then install the evaporator on the wooden board.Install high and low pressure pipelines: first open a (50mm) hole in the car, and then install the rubber cover with three holes. The thick pipe is the low pressure pipe and is connected to the compressor. The thin tube is a high pressure tube and is connected to the condenser. Then connect the other end of the high and low pressure pipes to the holes corresponding to the expansion valve of the indoor unit, use long black screws and iron sheets to clamp the aluminum joints, and tighten the screws.Install the connection line: connect the connection lines of the internal and external units, plug the power cord plugs into each other, and connect the drain pipe of the evaporator.Vacuuming/Adding refrigerant: It needs to be vacuumed for 15-20 minutes, and then add refrigerant R134a/600g. The refrigerant can be added according to the pressure value. Generally, after the R134a refrigerant is injected into the air conditioning system, the pressure at the low pressure port is 35psi, and the pressure at the high pressure port is 140-180psi.Connect the power cord: Connect the power cord to the battery, pay attention to the positive and negative poles of the battery, do not connect them wrongly, + positive / - negative. It is forbidden to connect it to the power-off switch and the power switch.Turn on the air conditioner: Drive the air conditioner to see if it works properly. If the current is insufficient, the refrigerant is too much or not enough, the control panel will display a code, which can quickly troubleshoot.
The product is a 12V 12000 BTU Split AC truck air conditioner designed for semi-trucks, buses, RVs, and caravans. It uses R1234yf/R134a refrigerant and has a refrigeration capacity of 1-3KW. The air conditioner features a white color, LED display screen, and is 100% leak tested for durability. It does not require drilling or modification for installation and comes with a 2-year manufacturer warranty. With a power consumption of 80W and noise level below 70dB, this portable air conditioner offers a comfortable and efficient cooling solution for vehicles.
Control panel and remote control---Intelligent, convenient, comfortable.Intelligent panel temperature setting and four frequency modulation modes.Convenient infrared remote control. Strong refrigeration---After stopping and extinguishing, it can continue to run for 8-12 hours to save energy and electricity, protect the environment, promote health, and sustain reshaping 4 working mode---Air supply mode，Power saving mode，Economic mode，Strong mode.Highefficency Fan --360 degree full waterproofelectronic Fan.High Quality Condenser --Special surface treatment,corrosion resistance,larger heat disssipation area,better refrigeration effect.Inverter scroll comcompressor--Intelligent inverter scroll compressor,more powerful and cooling faster.Often drivers leave the engine running for hours to use the air conditioner when parked or resting at night, which is bad for the environment, wastes a lot of fuel and wears out the engine faster. The parking air conditioner is powered by truck batteries and does not require an engine, saving energy and fuel while providing a safe and comfortable environment for the driver.Wide range of uses, suitable for trucks, RVs, vans, passenger cars, excavators, agricultural vehicles, boats, engineering vehicles, etc.Scroll compressorr: compared with other compressors, whether in terms of refrigeration efficiency or working efficiency, this compressor The compressor has nearly doubled the efficiency, which is better than the traditional split compressor refrigeration. Powered by an on-board battery, it keeps your cab cool even when the engine is off.
Matters needing attention1、 There is no refrigerant inside the air conditioner, and 500-550g R1234yf/R134a needs to be added 2、Refrigeration oil type: POE68(included)3、Vacuum for 10 minutes before adding refrigerant until the low pressure gauge shows a negative value.4、Parking air conditioning Battery Requirements
12V: At least 100AH single battery and 70A generator are required.
24V: At least 80AH single battery and 60A generator are required.
Install the external machine: remove the casing, mark the drilling position, use an 8mm drill to drill holes, use a riveting tool to fix the rivet nut at the drilling point, install shock pads and sleeves at the holes of the external machine, and fix the external machine to the car .Install the expansion valve: remove the iron sheet at the position of the expansion valve of the evaporator, and fix the expansion valve to the evaporator. The two black screws correspond to the two holes, so there is no need to worry about wrong installation.Then wrap it in black cotton wrap.Install the indoor unit: first install the wooden board to the indoor wall, and then install the evaporator on the wooden board.Install high and low pressure pipelines: first open a (50mm) hole in the car, and then install the rubber cover with three holes. The thick pipe is the low pressure pipe and is connected to the compressor. The thin tube is a high pressure tube and is connected to the condenser. Then connect the other end of the high and low pressure pipes to the holes corresponding to the expansion valve of the indoor unit, use long black screws and iron sheets to clamp the aluminum joints, and tighten the screws.Install the connection line: connect the connection lines of the internal and external units, plug the power cord plugs into each other, and connect the drain pipe of the evaporator.Vacuuming/Adding refrigerant: It needs to be vacuumed for 15-20 minutes, and then add refrigerant R134a/600g. The refrigerant can be added according to the pressure value. Generally, after the R134a refrigerant is injected into the air conditioning system, the pressure at the low pressure port is 35psi, and the pressure at the high pressure port is 140-180psi.Connect the power cord: Connect the power cord to the battery, pay attention to the positive and negative poles of the battery, do not connect them wrongly, + positive / - negative. It is forbidden to connect it to the power-off switch and the power switch.Turn on the air conditioner: Drive the air conditioner to see if it works properly. If the current is insufficient, the refrigerant is too much or not enough, the control panel will display a code, which can quickly troubleshoot.
